Schweitzer Engineering Laboratories SEL-701 - Page 399

Date Code 20010719 701 Motor Protection Relay
Date ___________
Created by ___________
Factory Defaults
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP7 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP7 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP8 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP8 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP9 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP9 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP10 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP10 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP11 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP11 = (Hidden)
RTD Trip Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F TRTMP12 = (Hidden)
RTD Alarm Temperature
Range: OFF, 0°–250°C
OFF, 32
°–482°F ALTMP12 = (Hidden)
Enable Winding Trip Voting
Range: Y, N EWNDGV = (Hidden)
Enable Bearing Trip Voting
Range:Y, N EBRNGV = (Hidden)
Enable RTD Biasing
(Hidden if no RTDnLOC = AMB, or if all winding RTD trip temperatures are OFF.)
Range: Y, N RTDBEN = (Hidden)
Page 9 of 17
