Schweitzer Engineering Laboratories SEL-701 - Page 400

701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
VOLTAGE-BASED PROTECTION
Undervoltage (U/V) Elements
(Hidden if no voltage option or if DELTA_Y = Y)
Level 1 Phase-Phase U/V Pickup
Range: OFF, 1–300 V 27P1P = (Hidden)
Level 2 Phase-Phase U/V Pickup
Range: OFF, 1–300 V 27P2P = (Hidden)
Overvoltage (O/V) Elements
(Hidden if no voltage option or if DELTA_Y = Y)
Level 1 Phase-Phase O/V Pickup
Range: OFF, 1–300 V 59P1P = (Hidden)
Level 2 Phase-Phase O/V Pickup
Range: OFF, 1–300 V 59P2P = (Hidden)
Undervoltage (U/V) Elements
(Hidden if no voltage option or if DELTA_Y = D)
Level 1 Phase U/V Pickup
Range: OFF, 1–300 V 27P1P = 40
Level 2 Phase U/V Pickup
Range: OFF, 1–300 V 27P2P = OFF
Overvoltage (O/V) Elements
(Hidden if no voltage option or if DELTA_Y = D)
Level 1 Phase O/V Pickup
Range: OFF, 1–300 V 59P1P = 73
Level 2 Phase O/V Pickup
Range: OFF, 1–300 V 59P2P = OFF
Residual O/V Pickup
(Hidden if SINGLEV = Y)
Range: OFF, 1–300 V 59GP = OFF
Reactive Power (VAR) Element Settings
(Hidden if no voltage option)
Negative VAR Alarm Pickup
Range: OFF, 30–2000 VAR; ITAP = 5 A
OFF, 6–400 VAR; ITAP = 1 A
NVARAP = OFF
Positive VAR Alarm Pickup
(Hidden if NVARAP = OFF)
Range: 30–2000 VAR; ITAP = 5 A
6–400 VAR; ITAP = 1 A
PVARAP = (Hidden)
VAR Alarm Time Delay
(Hidden if NVARAP = OFF)
Range: 0.00–400.00 s VARAD = (Hidden)
Page 10 of 17
