Date Code 20010719 701 Motor Protection Relay
Date ___________
Created by ___________
Factory Defaults
Negative VAR Trip Pickup
Range: OFF, 30–2000 VAR; ITAP = 5 A
OFF, 6–400 VAR; ITAP = 1 A
NVARTP = OFF
Positive VAR Trip Pickup
(Hidden if NVARTP = OFF)
Range: 30–2000 VAR; ITAP = 5 A
6–400 VAR; ITAP = 1 A
PVARTP = (Hidden)
VAR Trip Time Delay
(Hidden if NVARTP = OFF)
Range: 0.00–400.00 s VA R T D = (Hidden)
VAR Element Arming Delay
(Hidden if both NVARAP and NVARTP = OFF)
Range: 0.00–15000 s VARDLY = (Hidden)
Underpower Element Settings (Hidden if no voltage option)
Phase Underpower Alarm Pickup
Range: OFF, 30–2000 W; ITAP = 5 A
OFF, 6–400 W; ITAP = 1 A
37PAP = OFF
Phase Underpower Alarm Time Delay
(Hidden if 37PAP = OFF)
Range: 0.00–400.00 s 37PAD = (Hidden)
Phase Underpower Trip Pickup
Range: OFF, 30–2000 W; ITAP = 5 A
OFF, 6–400 W; ITAP = 1 A
37PTP = OFF
Phase Underpower Trip Time Delay
(Hidden if 37PTP = OFF)
Range: 0.00–400.00 s 37PTD = (Hidden)
Underpower Element Arming Delay
(Hidden if both 37PAP and 37PTP = OFF)
Range: 0–15000 s 37DLY = (Hidden)
Power Factor Element Settings (Hidden if no voltage option)
Power Factor Alarm Leading Pickup
Range: OFF, 0.05–0.99 55LDAP = OFF
Power Factor Alarm Lagging Pickup
(Hidden if 55LDAP = OFF)
Range: 0.05–0.99 55LGAP = (Hidden)
Power Factor Alarm Time Delay
(Hidden if 55LDAP = OFF)
Range: 0.00–400.00 s 55AD = (Hidden)
Power Factor Trip Leading Pickup
Range: OFF, 0.05–0.99 55LDTP = OFF
Power Factor Trip Lagging Pickup
(Hidden if 55LDTP = OFF)
Range: 0.05–0.99 55LGTP = (Hidden)
Power Factor Trip Time Delay
(Hidden if 55LDTP = OFF)
Range: 0.00–400.00 s 55TD = (Hidden)
Power Factor Element Arming Delay
(Hidden if both 55LDAP and 55LDTP = OFF)
Range: 0–15000 s 55DLY = (Hidden)
Page 11 of 17
To Next Page
