701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
Frequency Elements Settings (Hidden if no voltage option)
Level 1 Pickup
Range: OFF, 20.00–70.00 Hz 81D1P = 59.10
Level 1 Time Delay
(Hidden if 81D1P = OFF)
Range: 0.03–400.00 s 81D1D = 0.03
Level 2 Pickup
Range: OFF, 20.00–70.00 Hz 81D2P = OFF
Level 2 Time Delay
(Hidden if 81D2P = OFF)
Range: 0.03–400.00 s 81D2D = (Hidden)
Level 3 Pickup
Range: OFF, 20.00–70.00 Hz 81D3P = OFF
Level 3 Time Delay
(Hidden if 81D3P = OFF)
Range: 0.03–400.00 s 81D3D = (Hidden)
Page 12 of 17
