Schweitzer Engineering Laboratories SEL-701

To Next Page

To Previous Page

701 Motor Protection Relay Date Code 20010719

Date ___________

Created by ___________

Factory Defaults

DM5_0 =

DM6_1 =

DM6_0 =

Output Contact Settings

Enable TRIP Contact Fail-Safe

Range: Y, N TRFS = Y

Enable OUT1 Contact Fail-Safe

Range: Y, N OUT1FS = N

Enable OUT2 Contact Fail-Safe

Range: Y, N OUT2FS = N

Enable OUT3 Contact Fail-Safe

Range: Y, N OUT3FS = N

Minimum Trip Duration Time

Range: 0.00–400.00 s TDURD = 0.5

Antibackspin Setting

Antibackspin Starting Delay

Range: 0–60 min ABSDLY = 0

Factory Logic Settings

Use Factory Logic Settings

Range: Y, N FACT LOG = Y
