Date Code 20010719 701 Motor Protection Relay
Date ___________
Created by ___________
Factory Defaults
SERIAL PORT SETTINGS (SERIAL
PORT COMMAND SET P F OR SET P R)
SET P Serial Port Settings
Protocol (Hidden, Equal ASCII for Front Port)
Range: ASCII, MOD PROTO = ASCII
Protocol = ASCII (Hidden when Protocol = MOD)
Baud Rate
Range: 300–19200 SPEED = 2400
Data Bits
Range: 7, 8 BITS = 8
Parity
Range: O, E, N PARITY = N
Stop Bits
Range: 1, 2 STOP = 1
Timeout
Range: 0–30 min T_OUT = 15
Send Auto Messages to Port
Range: Y, N AUTO = N
Enable Hardware Handshaking
Range: Y, N RTSCTS = N
Fast Operate Enable
Range: Y, N FASTOP = N
Protocol = MOD (Hidden when Protocol = ASCII)
Baud Rate
Range: 300–19200 SPEED = 2400
Parity
Range: O, E, N PARITY = N
Modbus
â
Slave ID
Range: 1–247 SLAVEID = 1
Page 15 of 17
