Schweitzer Engineering Laboratories SEL-701 - Page 406

701 Motor Protection Relay Date Code 20010719
Date ___________
Created by ___________
Factory Defaults
SEQUENTIAL EVENTS
RECORDER SETTINGS (SET R)
SER Trigger Settings
SER1
Range: 24 Relay Word bits, separated by
commas.
Use NA to disable setting.
SER1 = IN1, IN2, IN3, IN4, IN5, IN6, IN7
SER2
Range: 24 Relay Word bits, separated by
commas.
Use NA to disable setting.
SER2 = STARTING, RUNNING, STOPPED, JAMTRIP, LOSSALRM,
LOSSTRIP, 46UBA, 46UBT, 49A, 49T,47T, SPEEDSW, SPEEDSTR,
TRIP, OUT1, OUT2, OUT3, 50G1T, 50G2T, 50N1T, 50N2T
SER3
Range: 24 Relay Word bits, separated by
commas.
Use NA to disable setting.
SER3 = RTDFLT, WDGALRM, WDGTRIP, BRGALRM,
BRGTRIP, AMBALRM, AMBTRIP, OTHALRM, OTHTRIP, 81D1T,
81D2T, 81D3T, TRGTR, START, 50P1T, 50P2T
SER4
Range: 24 Relay Word bits, separated by
commas.
Use NA to disable setting.
SER4 = NA
SER Alias Settings
Enable ALIAS Settings
Range: N, 1–20 EALIAS = 17
