701 Motor Protection Relay Date Code 20010719
SEL-701 Serial Port Command Summary (Continued)
Access
Level
Serial Port
Command
Command Description
Page Number
Event Analysis Commands
1 EVENT View event reports 6.13
1 HISTORY View event summaries/histories 6.13
2 HISTORY R Reset event history data 6.14
1 SER View sequential events recorder data 6.21
2 SER R Reset sequential events recorder data 6.22
1 TARGET Display relay element status 6.27
1 TARGET R Reset target LEDs 6.30
1 TRIGGER Trigger an event report 6.31
Motor Data Commands
1 LDP Display load profile data 6.14
1 LDP D Display load profile buffer size 6.15
2 LDP R Reset load profile data 6.15
1 MOTOR Display motor statistics 6.18
2 MOTOR R Reset motor statistics 6.19
1 MSR Display motor start reports 6.19
1 MSR F Display the format of a motor start report 6.19
1 MST Display motor start trend data 6.19
2 MST R Reset motor start trend data 6.19
2 RLP Reset learned motor parameters 6.21
Relay Setting Commands
1 SHOW Show/view relay settings 6.24
2 SET Enter/change relay settings 6.22
Relay Output Control Commands
2 ANALOG Test analog output 6.11
2 CON Control remote bit 6.12
2 PUL Pulse output contact 6.20
2 STOP Stop motor 6.27
2 STR Start motor 6.27
