xiii
Date Code 20090730 Instruction Manual SEL-734 Meter
Preface
Safety and General Information
Examples
This instruction manual uses several example illustrations and instructions to explain how to
effectively operate the SEL-734. These examples are for demonstration purposes only; the
firmware identification information or settings values included in these examples may not
necessarily match those in the current version of your SEL-734.
Safety and General Information
Safety Information
This manual uses three kinds of hazard statements, formatted as follows:
Symbols
The following symbols from EN 61010-1 are often marked on SEL products.
Laser
The SEL-734 is a Class 1 LED Product and complies with IEC 60825-1:1993 + A1:1997 +
A2:2001. The following figure shows the compliance label that is located on the left side of
the device (when facing the front of the device). Figure 2.4 shows the location of the Class 1
LED, PORT F (the front optical port), on the front panel of the SEL-734.
Typographic Conventions
Example Description
STATUS Commands typed at a command line interface on a PC.
<Enter> Single keystroke on a PC keyboard.
<Ctrl+D> Multiple/combination keystroke on a PC keyboard.
Start > Settings PC dialog boxes and menu selections. The > character indicates submenus.
RESET Meter front-panel pushbuttons.
ENABLE Meter front- or rear-panel labels.
MAIN > METER
Meter front-panel LCD menus and meter responses. The > character indicates submenus.
Indicates a potentially
hazardous situation
that, if not avoided,
may result in minor or
moderate injury or
equipment damage.
!
CAUTION
!
WARNING
Indicates a potentially
hazardous situation
that, if not avoided,
could result in death or
serious injury.
Indicates an
imminently hazardous
situation that, if not
avoided, will result in
death or serious injury.
!
DANGER
Symbol 14
Consult Documentation for Additional Information
Symbol 6
Protective (Safety) Ground Conductor Terminal
Symbol 1
Direct Current
Symbol 2
Alternating Current
Symbol 3
Direct and Alternating Current
Symbol 5
Earth (Ground) Terminal
