Meter Word Bits (Used in SEL
OGIC Control Equations)
18 7 SV01 SELOGIC control equation variable
timer input SV1 asserted
6SV02 SEL
OGIC control equation variable
timer input SV2 asserted
5SV03 SEL
OGIC control equation variable
timer input SV3 asserted
4SV04 SEL
OGIC control equation variable
timer input SV4 asserted
3 SV01T SEL
OGIC control equation variable
timer output SV1T asserted
2 SV02T SEL
OGIC control equation variable
timer output SV2T asserted
1 SV03T SEL
OGIC control equation variable
timer output SV3T asserted
0 SV04T SEL
OGIC control equation variable
timer output SV4T asserted
19 7 SV05 SEL
OGIC control equation variable
timer input SV5 asserted
6SV06 SEL
OGIC control equation variable
timer input SV6 asserted
5SV07 SEL
OGIC control equation variable
timer input SV7 asserted
4SV08 SEL
OGIC control equation variable
timer input SV8 asserted
3 SV05T SEL
OGIC control equation variable
timer output SV5T asserted
2 SV06T SEL
OGIC control equation variable
timer output SV6T asserted
1 SV07T SEL
OGIC control equation variable
timer output SV7T asserted
0 SV08T SEL
OGIC control equation variable
timer output SV8T asserted
20 7 SV09 SEL
OGIC control equation variable
timer input SV9 asserted
6SV10 SEL
OGIC control equation variable
timer input SV10 asserted
5SV11 SEL
OGIC control equation variable
timer input SV11 asserted
4SV12 SEL
OGIC control equation variable
timer input SV12 asserted
3 SV09T SEL
OGIC control equation variable
timer output SV9T asserted
2 SV10T SEL
OGIC control equation variable
timer output SV10T asserted
1 SV11T SEL
OGIC control equation variable
timer output SV11T asserted
0 SV12T SEL
OGIC control equation variable
timer output SV12T asserted
Table 9.4 SEL-734 Meter Word Bit Definitions
(Sheet 5 of 12)
Row Bit Definition
21 7 SV13 SELOGIC control equation variable
timer input SV13 asserted
6SV14 SEL
OGIC control equation variable
timer input SV14 asserted
5SV15 SEL
OGIC control equation variable
timer input SV15 asserted
4SV16 SEL
OGIC control equation variable
timer input SV16 asserted
3 SV13T SEL
OGIC control equation variable
timer output SV13T asserted
2 SV14T SEL
OGIC control equation variable
timer output SV14T asserted
1 SV15T SEL
OGIC control equation variable
timer output SV15T asserted
0 SV16T SEL
OGIC control equation variable
timer output SV16T asserted
22 7 RB01 Remote bit 1 asserted
6 RB02 Remote bit 2 asserted
5 RB03 Remote bit 3 asserted
4 RB04 Remote bit 4 asserted
3 RB05 Remote bit 5 asserted
2 RB06 Remote bit 6 asserted
1 RB07 Remote bit 7 asserted
0 RB08 Remote bit 8 asserted
23 7 RB09 Remote bit 9 asserted
6 RB10 Remote bit 10 asserted
5 RB11 Remote bit 11 asserted
4 RB12 Remote bit 12 asserted
3 RB13 Remote bit 13 asserted
2 RB14 Remote bit 14 asserted
1 RB15 Remote bit 15 asserted
0 RB16 Remote bit 16 asserted
24 7 LT01 Latch bit 1 asserted
6 LT02 Latch bit 2 asserted
5 LT03 Latch bit 3 asserted
4 LT04 Latch bit 4 asserted
3 LT05 Latch bit 5 asserted
2 LT06 Latch bit 6 asserted
1 LT07 Latch bit 7 asserted
0 LT08 Latch bit 8 asserted
25 7 LT09 Latch bit 9 asserted
6 LT10 Latch bit 10 asserted
5 LT11 Latch bit 11 asserted
Table 9.4 SEL-734 Meter Word Bit Definitions
(Sheet 6 of 12)
Row Bit Definition
