Operating Instructions
CLV 480 Bar Code Scanner
I-10 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Abbreviations
AMV/S Connection Module with signal distribution/with additional power supply pack
BMV/S Bus Connection module with signal distribution/with additional power supply
CAN Controller Area Network (standard field bus system with message-orientated data ex-
change protocol)
CLV Code-Leser V-Prinzip
DC Distance Configuration
DOF Depth Of Field
EEPROM Electrically Erasable Programmable Read Only Memory
HD High Density
HTML Hyper Text Markup Language (page-description language on the internet)
LED Light Emitting Diode
MTBF Mean Time Between Failure
PLC Programmable Logic Controller
RAM Ramdom Acces Memory
ROM Read Only Memory
RTF Rich Text Format (standard document format with format descriptions)
SMART SICK Modular Advanced Recognition Technology
Tables
Table 3-1: CLV variants ........................................................................................................................ 3-1
Table 3-2: Meaning of LEDs: CLV without external parameter memory .........................3-10
Table 3-3: Meaning of LEDs: CLV with external parameter memory................................3-11
Table 4-1: Permissible reading angles between the scan line and bar code ................. 4-5
Table 5-1: Connection Modules for the CLV ................................................................................ 5-1
Table 5-2: Cables for connecting the CLV..................................................................................... 5-2
Table 5-3: Pin assignment of the 15-pin D Sub HD "Host/Term" plug ............................. 5-7
Table 5-4: Pin assignment of the 15-pin D Sub HD "I/O" socket........................................ 5-7
Table 5-5: Pin assignment of the 15-pin D Sub HD "Host/Term" cable plug ................. 5-8
Table 5-6: Pin assignment of the 15-pin D Sub HD "I/O" cable socket............................ 5-8
Table 5-7: Maximum cable lengths between the CLV and host........................................... 5-9
Table 5-8: Power consumption of the CLV ................................................................................... 5-9
Table 5-9: Power-up delay as a function of the device number GN................................... 5-9
Table 5-10: Wire color assignment of the cable no. 2 020 303 ........................................5-10
Table 5-11: Wire color assignment of the cable no. 2 020 264..........................................5-11
Table 5-12: Wire color assignment of cable 1 for external parameter
memory no. 2 020 981 ...............................................................................................5-12
Table 5-13: Wire color assignment of cable 2 for external parameter
memory no. 2 020 981 ...............................................................................................5-12
Table 5-14: Wire color assignment cable 1 for connector cover no. 2 021 267..........5-13
Table 5-15: Wire color assignment cable 2 for connector cover no. 2 021 267..........5-13
Table 5-16: Communication parameters for the host interface (default setting)...........5-15
Table 5-17: Characteristic data of the "Sensor" switching input ..........................................5-17
Table 5-18: Pin and terminal assignment for "IN 0" to "IN 4" switching inputs..............5-19
Table 5-19: Characteristic data of the "IN 0" to "IN 4" switching inputs...........................5-19
Table 5-20: Dynamic focus control: switching inputs/distance
configuration assignment table..................................................................................5-19
Table 5-21: Combination of the functions of the "IN 0" to "IN 4" switching inputs.......5-20
Table 5-22: Pin and terminal assignment for "Result 1" to "Result 4"
switching outputs ............................................................................................................5-21
