SICK microScan3 - EFI-pro User Manual

CAUTION
Ob
serving the safety laser scanner through optical instruments (such as magnifying
glasses, lenses, telescopes) may be hazardous for the eyes.
b
Do not look directly at the laser beam source using optical instruments.
2.2 Intended use
The safety laser scanner is an electro-sensitive protective device (ESPE) and is suitable
f
or the following applications:
•
Hazardous area protection
•
Hazardous point protection
•
Access protection
•
Mobile hazardous area protection (e.g. protection from automated guided vehi‐
cles)
The safety laser scanner must only be used within the limits of the prescribed and
s
pecified technical data and operating conditions at all times.
Incorrect use, improper modification of or tampering with the safety laser scanner will
invalidate any warranty from SICK; in addition, any responsibility and liability of SICK for
damage and secondary damage caused by this is excluded.
2.3 Inappropriate use
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
The safety laser scanner works as an indirect protective measure and cannot provide
protection from pieces thrown from application nor from emitted radiation. Transparent
objects are not detected.
b
You must only use the safety laser scanner as an indirect protective measure.
The safety laser scanner is not suitable for the following applications, among others:
•
Out
doors
•
Underwater
•
In explosion-hazardous areas
2.4 Requirements for personnel qualifications
The safety laser scanner must only be configured, installed, connected, commissioned
and ser
viced by qualified safety personnel.
Project planning
For project planning, a person is considered competent when he/she has expertise and
experience in the selection and use of protective devices on machines and is familiar
with the relevant technical rules and national work safety regulations.
Mechanical mounting
For mechanical mounting, a person is considered competent when he/she has the
expertise and experience in the relevant field and is sufficiently familiar with the appli‐
cation of the protective device on the machine that he/she can assess its operational
safety status.
SAFETY INFORMATION 2
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
11
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
