SICK microScan3 - EFI-pro User Manual

13 Technical data
13.1 Variant overview
Ordering information: see "Or
dering information", page 168.
Table 26: Devices and type codes
Performance pack‐
a
ge
Integration in the
control
Protective field
range
Device without sys‐
tem plug
System plug Position of the
system plug
when delivered
Device with system
plug
•
C
ore
•
EFI-pro
≤ 4.0 m MICS3-ABAZ40ZA1 MICSX-BANNZZZZ1 Bottom MICS3-ABAZ40ZA1P01
≤ 4.0 m Rear MICS3-ABAZ40ZA1P03
≤ 5.5 m MICS3-ABAZ55ZA1 Bottom MICS3-ABAZ55ZA1P01
≤ 9.0 m MICS3-ABAZ90ZA1 Bottom MICS3-ABAZ90ZA1P01
≤ 9.0 m Rear MICS3-ABAZ90ZA1P03
•
Pr
o
•
EFI-pro
≤ 4.0 m MICS3-CBAZ40ZA1 MICSX-BANNZZZZ1 Bottom MICS3-CBAZ40ZA1P01
≤ 5.5 m MICS3-CBAZ55ZA1 Bottom MICS3-CBAZ55ZA1P01
≤ 5.5 m Rear MICS3-CBAZ55ZA1P03
≤ 9.0 m MICS3-CBAZ90ZA1 Bottom MICS3-CBAZ90ZA1P01
≤ 9.0 m Rear MICS3-CBAZ90ZA1P03
13.2 Version numbers and functional scope
Functional scope
Older de
vices might not support the full functional scope of the latest Safety Designer.
To identify the different levels of the functionality, we use a 3-digit version number. The
version number is marked with the letter V on the device.
The functional scope of the device can be read at the following locations:
•
Label on the device
•
Display, entry in the menu Device information under Hardware
•
Safety Designer, Overview dialog box (only with connected devices)
•
Safety Designer, report
Table 27: microScan3 Core – EFI-pro functional scope
Version number Amendments and new functions
1.0.0
•
F
irst published version
Table 28: microScan3 Pro – EFI-pro functional scope
Version number Amendments and new functions
1.0.0
•
First published version
Revision
In some c
ases, new system plugs are not suitable for older devices.
The different revision statuses of the devices are identified by “Rev” followed by a
three-digit version number. New devices have a label which indicates the revision sta‐
tus.
New system plugs have a label which indicates the devices for which they are suitable.
TECHNICAL DATA 13
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
151
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
