SICK microScan3 - EFI-pro User Manual

Table 29: Compatibility
Label on the device Label on the system plug Compatible
– – Yes
– Only compatible with Rev
≥ 1.1.0
Information is available from
y
our SICK subsidiary.
Rev 1.1.0 – Yes
Rev 1.1.0 Only compatible with Rev
≥ 1.1.0
Yes
Rev 1.2.0 – Yes
Rev 1.2.0 Only compatible with Rev
≥ 1.1.0
Yes
13.3 Data sheet
13.3.1 microScan3 – EFI-pro
Features
T
able 30: Features
microScan3 Core – EFI-pro microScan3 Pro – EFI-pro
Protective field range
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 4.0 m, details: see "Sensing range", page 158
Devices with a max. protec‐
t
ive field range of 5.5 m
≤ 5.5 m, details: see "Sensing range", page 158
Devices with a max. protec‐
tive field range of 9.0 m
≤ 9.0 m, details: see "Sensing range", page 158
Scanning range of the refer‐
ence contour field
Same as protective field range, see "Sensing range", page 158
Scanning range of the con‐
t
our detection field
Same as protective field range, see "Sensing range", page 158
Warning field range
Devices with a max. protec‐
tive field range of 4.0 m
≤ 40 m
Devices with a max. protec‐
t
ive field range of 5.5 m
≤ 40 m
Devices with a max. protec‐
tive field range of 9.0 m
≤ 64 m
Distance measurement range
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 40 m
Devices with a max. protec‐
tive field range of 5.5 m
≤ 40 m
Devices with a max. protec‐
t
ive field range of 9.0 m
≤ 64 m
Fields ≤ 8 ≤ 128
Simultaneously monitored fields
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 4 ≤ 8
Devices with a max. protec‐
tive field range of 5.5 m
≤ 4 ≤ 8
13 TECHNICAL DATA
152
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro 8021913/15ZW/2019-11-14 | SICK
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
