13.6 Data exchange in the network
13.6.1 Assemblies
13.6.1.1 Available data
13.6.1.1.1 Input of the device (output of the control)
Table 41: Input of the device (output of the control)
Name Usage Data type Definition Values Safety implica‐
t
ion
ActivateCaseSwitching Safety function BOOL Monitoring case switch‐
ing
Activates switching
between monitoring
cases. Only valid sig‐
nals are then permitted
for switching between
monitoring cases.
0 = switching
between monitor‐
ing cases not
activated
Safety-relevant
parameter
1 = switching
between monitor‐
ing cases acti‐
vated
control input 1 (A1) Safety function BOOL Control input 1 (A1)
C
ontrol input for switch‐
ing between monitoring
cases. Control inputs
can be evaluated in a
complementary way in
pairs or with a 1-off-n-
condition.
0 = logic status
of the control
input is 0
Safety-relevant
parameter
1 = logic status
of the control
input is 1
control input 2 (A2)
...
cont
rol input 16 (H2)
Safety function BOOL Control input 2 (A2) …
16 (H2)
Control input for switch‐
ing between monitoring
cases. Control inputs
can be evaluated in a
complementary way in
pairs or with a 1-off-n-
condition.
1)
0 = logic status
of the control
input is 0
Safety-relevant
parameter
1 = logic status
of t
he control
input is 1
TriggerResetCutOffPath01 Safety function BOOL Reset Cut-off path 01
R
eset of the restart
interlock of cut-off path
01. Resetting is per‐
formed with the rising
signal flank.
0 = no reset Safety-relevant
parameter
0-1-0 = reset
(duration of sta‐
tus 1 ≥ 60 ms)
TriggerResetCutOffPath02
...
T
riggerResetCutOffPath08
Safety function BOOL Reset Cut-off path 02
… 08
Reset of the restart
interlock of cut-off path
02 to 08. Resetting is
performed with the ris‐
ing signal flank.
2)
0 = no reset Safety-relevant
parameter
0-1-0 = reset
(dur
ation of sta‐
tus 1 ≥ 60 ms)
TriggerRunMode Safety function BOOL Restart safety function
R
estarts the safety
function after an appli‐
cation error. (The
device must also be
restarted to end the
error state.)
0 = no start com‐
mand
Safety-relevant
parameter
0-1-0 = start
safety function
(duration of sta‐
tus 1 ≥ 120 ms)
1 = ignored
