4 Project planning
4.1 Manufacturer of the machine
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
b
Use of the safety laser scanner requires a risk assessment. Check whether addi‐
tional protective measures are required.
b
Comply with the applicable national regulations derived from the application (e.g.,
work safety regulations, safety rules, or other relevant safety guidelines).
b
Apart from the procedures described in this document, the components of the
safety laser scanner must not be opened.
b
The safety laser scanner must not be tampered with or changed.
b
Improper repair of the protective device can lead to a loss of the protective func‐
tion. The protective device must only be repaired by the manufacturer or by some‐
one authorized by the manufacturer.
4.2 Operator of the machine
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
b
Changes to the electrical integration of the safety laser scanner in the machine
control and changes to the mechanical mounting of the safety laser scanner
necessitate a new risk assessment. The results of this risk assessment may
require the operator of the machine to meet a manufacturer’s obligations.
b
Changes to the device’s configuration may impair the protective function. The
effectiveness of the protective device must be checked after any change to the
configuration. The person carrying out the change is also responsible for maintain‐
ing the protective function of the device.
b
Apart from the procedures described in this document, the components of the
safety laser scanner must not be opened.
b
The safety laser scanner must not be tampered with or changed.
b
Improper repair of the protective device can lead to a loss of the protective func‐
tion. The protective device must only be repaired by the manufacturer or by some‐
one authorized by the manufacturer.
4.3 Assembly
This chapter contains important information about the design.
Information about the individual steps for mounting the device: see "Mounting",
page 63.
PROJECT PLANNING 4
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
25
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
