SICK microScan3 - EFI-pro

LED status Relevance Troubleshooting
Ö R
ed
Correctable error (e.g.,
E
FI-pro connection
interrupted)
b
R
eestablish EFI-pro connection.
Ö R
ed/green
Device self-test
D
evice is being config‐
ured
Configuration errors
b
C
onfigure device.
11.3 Diagnostics using the display
The display supplies information about the status of the safety laser scanner, and for
dia
gnostics and troubleshooting.
11.3.1 Status display
The display shows current information about the safety laser scanner’s status. The dis‐
pla
y switches off after approx. 60 s if all fields are clear and no other notification is dis‐
played.
b
If the display is switched off, press any pushbutton to activate the display.
b
Press any pushbutton to obtain more details about the displayed status informa‐
tion.
b
If there are a number of pages with detailed information, this is shown in the top
right of the display.
b
Press the arrow buttons to change between a number of pages with detailed infor‐
mation.
Table 23: Overview of status information
Display Device or configura‐
t
ion
Meaning
All devices and config‐
ur
ations
All fields clear, safety outputs in ON state.
The number at bottom right indicates the
active monitoring case.
Devices and configu‐
r
ations with a config‐
ured safety output
Protective field interrupted, safety output in
OFF state.
Devices and configu‐
r
ations with 2 to 4
configured safety out‐
puts
For every of 4 cut-off paths, the following
applies: the protective field is interrupted or
there is a warning field in the active monitoring
case. Safety outputs in the OFF state.
Each column stands for a safety output.
Safety outputs in the OFF state are marked
with a cross if they could be in the safety-
related ON state in at least one monitoring
case.
Devices and configu‐
r
ations with 2 to 4
configured safety out‐
puts
The protective field in position 3 is interrupted
or there is a warning field in the active monitor‐
ing case. The associated safety output is in the
OFF state.
Safety outputs for which no field is interrupted
and which are in the ON state are marked with
their number.
11 TROUBLESHOOTING
