SICK microScan3 - EFI-pro User Manual

14 Ordering information
14.1 Scope of delivery
•
S
afety laser scanner with system plug
•
Safety note
•
Mounting Instructions
•
Operating instructions for download: www.sick.com
14.2 Ordering information
Table 45: microScan3 Core – EFI-pro ordering information
Integration in the con‐
t
rol
Protective field range Position of the system plug
when delivered
Type code Part number
EFI-pro ≤ 4.0 m Bottom MICS3-ABAZ40ZA1P01 1092539
EFI-pro ≤ 4.0 m Rear MICS3-ABAZ40ZA1P03 1102627
EFI-pro ≤ 5.5 m Bottom MICS3-ABAZ55ZA1P01 1092538
EFI-pro ≤ 9.0 m Bottom MICS3-ABAZ90ZA1P01 1094455
EFI-pro ≤ 9.0 m Rear MICS3-ABAZ90ZA1P03 1102628
Table 46: microScan3 Pro – EFI-pro ordering information
Integration in the con‐
t
rol
Protective field range Position of the system plug
when delivered
Type code Part number
EFI-pro ≤ 4.0 m Bottom MICS3-CBAZ40ZA1P01 1091037
EFI-pro ≤ 5.5 m Bottom MICS3-CBAZ55ZA1P01 1091038
EFI-pro ≤ 5.5 m Rear MICS3-CBAZ55ZA1P03 1103032
EFI-pro ≤ 9.0 m Bottom MICS3-CBAZ90ZA1P01 1094465
EFI-pro ≤ 9.0 m Rear MICS3-CBAZ90ZA1P03 1103033
14 ORDERING INFORMATION
168
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro 8021913/15ZW/2019-11-14 | SICK
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
