15 Spare parts
15.1 Safety laser scanner without system plug
Table 47: Safety laser scanner without system plug
Spare part for Type code Part number
Device Part number Protective field
ran
ge
microScan3 Core – EFI-
pr
o
1092539, 1102627 ≤ 4.0 m MICS3-ABAZ40ZA1 1069680
microScan3 Core – EFI-
pro
1092538 ≤ 5.5 m MICS3-ABAZ55ZA1 1069685
microScan3 Core – EFI-
pro
1094455, 1102628 ≤ 9.0 m MICS3-ABAZ90ZA1 1094453
microScan3 Pro – EFI-
pro
1091037 ≤ 4.0 m MICS3-CBAZ40ZA1 1069682
microScan3 Pro – EFI-
pr
o
1091038, 1103032 ≤ 5.5 m MICS3-CBAZ55ZA1 1069687
microScan3 Pro – EFI-
pro
1094465, 1103033 ≤ 9.0 m MICS3-CBAZ90ZA1 1094464
15.2 System plug
Table 48: System plug
Spare part for Connection type Type code Part number
Device Part number
microScan3 – EFI-pro 1092539,
1102627,
1092538,
1094455,
1102628,
1091037,
1091038,
1103032,
1094465,
1103033
M12 plug connector MICSX-BANNZZZZ1 2086102
15.3 Additional spare parts
Table 49: Additional spare parts
Part Part number
Optics cover (with seal and screws) 2073673
Cover plate, 91.8 mm × 31.3 mm (with screws) 2086094
SPARE PARTS 15
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
169
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
