16.7 Additional accessories

Table 61: Tools

Part Part number

Torque screwdriver with attachment for M12 plug connector 2081618

ACCESSORIES 16

8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro

175

Subject to change without notice
