SICK microScan3 - EFI-pro User Manual

5 Mounting
5.1 Safety
Information about the requirements for properly mounting the safety laser scanner, see
"A
ssembly", page 25.
DANGER
D
angerous state of the machine
b
Make sure that the dangerous state of the machine is (and remains) switched off
during mounting, electrical installation, and commissioning.
b
Make sure that the safety laser scanner’s outputs do not affect the machine dur‐
ing mounting, electrical installation, and commissioning.
DANGER
H
azard due to lack of effectiveness of the protective device
If unsuitable brackets are used or if subjected to excessive vibrations, the device may
become detached or damaged.
Persons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
b
Only use SICK-approved brackets for mounting.
b
Take appropriate measures for vibration damping if vibration and shock specifica‐
tions exceed the values and test conditions specified in the data sheet, see "Data
sheet", page 152.
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
b
Do not do repair work on device components.
b
Do not make changes to or manipulate device components.
b
Apart from the procedures described in this document, the device components
must not be opened.
NOTE
Mount t
he device in the following order.
5.2 Unpacking
b
T
he safety laser scanner’s optics cover is an optical component. Make sure that
the optics cover does not become dirty or scratched during unpacking and mount‐
ing. Prevent fingerprints on the optics cover.
b
Check the components for completeness and the integrity of all parts, see "Scope
of delivery", page 168.
b
Please contact your respective SICK subsidiary should you have any complaints.
5.3 Mounting procedure
The following options for mounting the safety laser scanner are available:
MOUNTING 5
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
63
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
