Fault type Brief description Cause Troubleshooting
N6 Invalid monitoring case
number
The monitoring case number
r
eceived via the network does not
match the configuration of the
device. The incorrect number is
applied for longer than 1 s.
b
Chec
k the configuration with the
Safety Designer.
b
Check the control over the net‐
work.
R1 Connection errors The data connection between the
cont
rol and device is interrupted.
b
Chec
k the connection between
the device and control.
b
Adjust the data transmission rate
in the control if necessary.
T1 Temperature error The Safety laser scanner’s operating
t
emperature has exceeded or fallen
below the permitted range.
b
Chec
k whether the safety laser
scanner is being operated in
accordance with the permissible
ambient conditions.
W1 Warnings exceed toler‐
ance t
ime
The combination of multiple warn‐
ings has resulted in a fault. The tol‐
erance time of 1 s has been
exceeded as there are multiple
warnings.
b
Use S
afety Designer to check
what warnings exist.
11.4 Diagnostics using Safety Designer
The following diagnostics tools are available in the device window:
•
D
ata recorder
•
Event history
•
Message history
The following interfaces are suitable for diagnostics:
•
U
SB 2.0 mini-B (female connector)
12)
•
Ethernet
12)
T
he USB connection may only be used temporarily and only for configuration and diagnostics.
11 T
ROUBLESHOOTING
144
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro 8021913/15ZW/2019-11-14 | SICK
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
