SICK microScan3 - EFI-pro User Manual

You will then configure the device offline. Diagnostics functions are not available.
Y
ou can connect the computer to the device later, assign a device to the device tile, and
transfer the configuration to the device.
7.2.3 User interface
Figure 54: Software controls
1
Menu bar
2
Toolbar
3
Main navigation
4
Working range
5
Device catalog
6
Task list and notes
7.2.4 User groups
The devices contain a hierarchy of user groups that regulate access to the devices.
T
he user groups’ settings and passwords are part of the configuration stored in the
device.
For certain actions (e.g., transferring a configuration to the device), you are requested
to log onto the device with the respective user group.
Table 9: User groups
User group Password Authorization
Machine operator Does not need a password (anyone
c
an log in as a machine operator).
May read configuration from the
device (if not blocked).
CONFIGURATION 7
8021913/15ZW/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
75
Subject to change without notice

SICK microScan3 - EFI-pro Specifications

General

Scanning angle	275°
Number of fields	Up to 128
Number of monitoring cases	Up to 128
Enclosure rating	IP65, IP67
Number of protective fields	Up to 128
Field sets	Up to 128
Protective field range	5.5 m
Resolution	30 mm / 40 mm / 50 mm / 70 mm / 150 mm
Interface	Ethernet/IP, PROFINET
Ambient operating temperature	0 °C ... +50 °C
Scanning range	5.5 m (protective)
Safety integrity level	SIL3 (IEC 61508)
Performance level	PL e (ISO 13849)
Type	Type 3
Detection capability	30 mm
Operating voltage	19.2 V DC to 30 V DC
Ambient temperature	0°C to +50°C
Storage temperature	-25 °C ... +70 °C
Housing material	Aluminum
Connection	M12 connector
Safety standards	IEC 61496-1, IEC 61508, ISO 13849
