Name Use Data type Definition Values Safety implica‐
t
ion
CurrentMonitoringCaseNoTa‐
ble2
Diagnostics USINT Current monitoring
case (Monitoring case
table 2)
Indicates the current
(active) monitoring case
of monitoring case
table 2.
0 = no monitor‐
ing case is active
Parameter with‐
out safety impli‐
cation
1 … 254 = num‐
ber of t
he current
(active) monitor‐
ing case
CurrentMonitoringCaseNoTa‐
ble3
Diagnostics USINT Current monitoring
c
ase (Monitoring case
table 3)
Signals the current
(active) monitoring case
of monitoring case
table 3.
0 = no monitor‐
ing case is active
Parameter with‐
out safety impli‐
cation
1 … 254 = num‐
ber of the current
(active) monitor‐
ing case
CurrentMonitoringCaseNoTa‐
ble4
Diagnostics USINT Current monitoring
c
ase (Monitoring case
table 4)
Indicates the current
(active) monitoring case
of monitoring case
table 4.
0 = no monitor‐
ing case is active
Parameter with‐
out safety impli‐
cation
1 … 254 = num‐
ber of the current
(active) monitor‐
ing case
DeviceError Diagnostics BOOL Device error
S
ignals whether an
application error (seri‐
ous error) is present,
causing the safety func‐
tion to be paused. To
resolve this, rectify the
cause of the error and
then restart the device.
0 = no device
error
Parameter with‐
out safety impli‐
cation
1 = device error
ManipulationStatus Diagnostics BOOL Manipulation
S
ignals if manipulation
has been detected
and the safety outputs
are therefore in the
OFF state, for example
because the device has
not detected an object
over a long period of
time.
0 = no manipula‐
tion detected
Parameter with
implication for
the safety func‐
tion
1 = manipulation
detected
NonsafeCutOffPath01 Additional func‐
t
ion
BOOL Cut-off path 01 (Not
safety-related)
The signal is ON if
the currently monitored
field in the cut-off path
is free.
0 = OFF state,
field interrupted
Parameter with‐
out safety impli‐
cation
1 = ON state,
f
ield free
NonsafeCutOffPath02
…
N
onsafeCutOffPath08
Additional func‐
tion
BOOL Cut-off path 02 … 08
(Not safety-related)
The signal is ON if
the currently monitored
field in the cut-off path
is free.
1)
0 = OFF state,
field interrupted
Parameter with‐
out safety impli‐
cation
1 = ON state,
field free
13 TECHNICAL DATA
180
O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET 8021219/1ELL/2022-01-21 | SICK
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
