Name Use Data type Definition Values Safety implica‐
t
ion
ReferenceContourStatus Diagnostics BOOL Reference contour
monitoring
The safety laser scan‐
ner does not detect any
contour within the con‐
figured tolerance band
of the reference con‐
tour field. All safety out‐
puts in the OFF state.
0 = contour in
the set tolerance
band or refer‐
ence contour
monitoring not
active
Parameter with
implication for
the safety func‐
tion
1 = contour not
in se
t tolerance
band
ResetRequiredCutOffPath01 Diagnostics BOOL Reset required, Cut-off
path 01
Signals whether the
device is waiting for a
reset signal to switch
safety-related cut-off
path 01 to the ON
state.
0 = reset not
required
Parameter with
implication for
the safety func‐
tion
1 = reset
required
ResetRequiredCutOffPath02
…
R
esetRequiredCutOffPath08
Diagnostics BOOL Reset required, Cut-off
path 02 … 08
Signals whether the
device is waiting for a
reset signal to switch
the respective safety-
related cut-off path to
the ON state.
1)
0 = reset not
required
Parameter with
implication for
the safety func‐
tion
1 = reset
required
RunModeactive Diagnostics BOOL Status of safety func‐
t
ion
Signals the operational
status of the device.
0 = safety func‐
tion paused.
Parameter with‐
out safety impli‐
cation
1 = safety func‐
tion is executed.
SafeCutOffPath01 Safety function BOOL Cut-off path 01 (safety-
or
iented)
The signal is ON, if all
of the following criteria
are met:
•
The currently moni‐
tored field in the
cut-off path is
safety-oriented
•
The currently moni‐
tored field in the
cut-off path is free
•
The restart interlock
was not triggered
0 = OFF state,
protective field
interrupted
Safety-relevant
parameter
1 = ON state,
protective field
free
TECHNICAL DATA 13
8021219/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET
