Service Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
12-64 HiPath 3000/5000 V9, Service documentation
service.fm
Guided Maintenance
Error Class 09 - Hardware Module Messages
09-000 !microprocessor
fault on, common
Microprocessor er-
ror.
Check power at the power
supply unit.
If this error persists, re-
place the central control
board.
09-001 !microprocessor
fault off, common
The microproces-
sor error has been
corrected.
None
09-002 !loadware memo-
ry fault on, com-
mon
Error in loadware
memory.
Replace the board if nec-
essary.
09-003 !loadware memo-
ry fault off, com-
mon
Error in loadware
memory has been
corrected.
None
09-029 !line interruption
(error on)
Line interruption Check the line and termi-
nal.
09-030 !short circuit (er-
ror on)
Short circuit on the
board specified.
Check the line, terminal,
and port.
09-031 !under voltage
(error on)
Under voltage. Check the power and line
at the terminal’s power
supply unit.
09-032 !thermal over-
load (error on)
The specified
board is overheat-
ed.
Check the fan and air sup-
ply in the 19” housing.
Note the ambient tempera-
ture.
09-036 !slip detected on
(STMD)
A bit slip has oc-
curred on an ISDN
line.
Check the S
0
line.
If necessary, reload the
board or perform a hard re-
start.
If the error persists, set up
an ISDN trace.
The problem
may be caused
by asynchro-
nous internal
and external
clock rates.
Data loss possi-
ble/connection
may be terminat-
ed.
Table 12-7 HiPath 3000 Class B Error Messages
No. HiPath 3000/
5000 Manager E:
Event Log Entry
Meaning Required Measures Note
