Installing HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

4-22 HiPath 3000/5000 V9, Service documentation

inst_h3.fm

Installing HiPath 3800

Examples for installation in a 19-inch cabinet

Caution

The height units represented in yellow in Figure 4-10 must be kept clear to ensure

adequate ventilation of the system cabinets.

Figure 4-10 HiPath 3800 - Installation Examples in the 19-Inch Cabinet

Examples of a 19-inch cabinet height of 1.92m with 37 height units

HiPath 3800

Basic cabinet

HiPath 3800

Basic cabinet

HiPath 3800

Expansion cabi-

net

Patch Panel
