Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
101
Number
Identifier
Name
20107
PROG_EVENT_IGN_INHIBIT
Prog events ignore the read-in disable
20108
PROG_EVENT_MASK
Eventdriven program calls
20109
PROG_EVENT_MASK_PROPERTIES
Prog event properties
20110
RESET_MODE_MASK
Initial setting at RESET
20112 START_MODE_MASK Initial setting at special NC Start after power-up and at
RESET
20116 IGNORE_INHIBIT_ASUP Execute user ASUPs completely in spite of reading
disable
20117 IGNORE_SINGLEBLOCK_ASUP Process user ASUPs completely in spite of single-block
processing
20700 REFP_NC_START_LOCK NC-Start disable without reference point
21000
CIRCLE_ERROR_CONST
Circle end point monitoring constant
20150
GCODE_RESET_VALUES
Reset G groups
20152
GCODE_RESET_MODE
G code basic setting at RESET
Auxiliary function settings of the channel
Number
Identifier
Name
Channel-specific
22000 AUXFU_ASSIGN_GROUP[n] Auxiliary function group [aux. func. no. in chan-
nel]: 0...63
22010
AUXFU_ASSIGN_TYPE[n]
Auxiliary function type [aux. func. no. in channel]: 0...63
22020 AUXFU_ASSIGN_EXTENSION[n] Auxiliary function extension [aux. func. no. in channel]:
0...63
22030 AUXFU_ASSIGN_VALUE[n] Auxiliary function value [aux. func. no. in channel]:
0...63
22550
TOOL_CHANGE_MODE
New tool offset for M function
Timers and counters of the channel
Number
Identifier
Name
Channel-specific
27860 PROCESSTIMER_MODE Activation of the program runtime measurement
27880
PART_COUNTER
Activation of the workpiece counters
27882
PART_COUNTER_MCODE[n]
Workpiece counting via M command, n = 0 ... 2
Display machine data
Number
Identifier
Name
283 ... 292
Setting of the display for the graphic simulation
10.7.2
Setting data
Number
Identifier
Name
Channel-specific
42000
THREAD_START_ANGLE
Start angle for thread
42010 THREAD_RAMP_DISP Starting and deceleration distance of feed axis in thread
cutting G33
42100
DRY_RUN_FEED
Dry run feedrate
