The following notation and abbreviations are used in this documentation:
● Programmable logic control (PLC) interface signals -> IS "Signal name" (signal data)
Example: IS "Feedrate override" (DB380x.DBB0)
The variable byte is located in the "to axis" range, x stands for the axis:
– 0: axis 1
– 1: axis 2
– n: axis n+1.
● Machine data -> MD MD_NR MD_NAME (description)
e.g.: MD30300 IS_ROT_AX (rotary axis)
● Setting data -> SD SD_NR SD_NAME (description)
e.g.: SD41200 JOG_SPIND_SET_VELO (JOG velocity for the spindle)
The machine and setting data are divided into the following areas:
Channel-specific machine data
Axis-specific machine data
Channel-specific setting data
Axis-specific setting data
Explanations for the technical data
Data types:
The following data types are used in the control:
● DOUBLE
Floating-point value (64-bit value)
Input limits from +/-4.19*10
-307
to +/-1.67*10
308
● DWORD
Integer values (32-bit values)
Input limits from -2,147,483,648 to +2,147,483,648 (decimal); as hexadecimal value: 0000 through FFFF
● BYTE
Integer values (8-bit values)
Input limits from -128 to +127 (decimal); as hexadecimal value: 00 through FF
● BOOLEAN
Boolean value: TRUE (1) or FALSE (0)
● STRING
Consisting of max. 16 American Standard Code for Information Interchange (ASCII) characters (upper-case letters,
numbers and underscore)
● Detailed explanations for the machine/setting data and interface signals used can be found in the SINUMERIK
808D/SINUMERIK 808D ADVANCED Parameter Manual.
● Detailed explanations of the alarms which may occur can be found in the SINUMERIK 808D/SINUMERIK 808D
ADVANCED Diagnostics Manual.
