Function Manual
01/2017
139
13.4
Measurement accuracy and functional testing
13.4.1
Measuring accuracy
Accuracy
The propagation time of the measuring signal is determined by the hardware used. The delay times are in the µs range plus
the probe response time.
The measurement uncertainty is calculated as follows:
Measurement uncertainty = measuring signal propagation time x traversing velocity
Correct results can only be guaranteed for traversing velocity where not more than one triggering signal arrives per position
controller cycle.
13.4.2
Probe functional test
Example of functional test
The functional test for the probe is conducted favorably via an NC program.
%_N_PRUEF_MESSTASTER_MPF
;Testing program probe connection
N10; R10
;Flag for trigger status
N20; R11: measurement in X axis
N30 T1 D1
; Preselect tool offset for probe
N40 ANF: G0 G90 X0 F150
;Starting position and meas. velocity
N50 MEAS=1 G1 X100
; Measurement at measuring input 1 in the X axis
N60 STOPRE
N70 R10=$AC_MEA[1]
; Read switching signal at 1st measuring input
N80 IF R10==0 GOTOF FEHL1
;Evaluation of signal
N90 R11=$AA_MW[X]
;Read in measured value in workpiece coordinates
N95 M0
N100 M2
N110 FEHL1: MSG
; Probe not switching!
N120 M0
N130 M2
Example of repeat accuracy
This program allows the measuring scatter (repeat accuracy) of the entire measuring system (machine-probe-signal
transmission) to be calculated.
In the example, ten measurements are taken in the X axis and the measured value recorded in the workpiece coordinates.
It is possible to determine the so-called "random dimensional deviations" which are not subject to any trend.
%_N_CHECK_ACCURATE_MPF
N05; R11
; Switching signal
N06 R12=1
; Counter
N10; R1 to R10
; MEAS_VAL_IN _X
N15 T1 D1
; Start conditions, preselect tool offset for
; probe
N20 ANF: G0 X0 F150
;Prepositioning in the measured axis
N25 MEAS=+1 G1 X100
; Measurement at 1st measuring input with
;rising switching edge, in the X axis
N30 STOPRE
; Stop decoding for subsequent evaluation of the
; result (automatically executed when reading
; MEA)
N35 R11= $AC_MEA[1]
; Read switching signal at 1st measuring input
N37 IF R11==0 GOTOF FEHL1
;Check switching signal
N40 R[R12]=$AA_MW[X]
;Read measured value in workpiece ;coordinates
N50 R12=R12+1
N60 IF R12<11 GOTOB ANF
;Repeat 10 times
N65 M0
N70 M02
N80 FEHL1: MSG
; Probe not switching
N90 M0
N95 M02
The measurement results R1 to R10 can be read after selecting the parameter display.
