Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
83
10.3.6
Program status
Program states
The status of the selected program is displayed in the interface in "AUTO" and "MDA" operating modes. If "JOG" operating
mode is selected when the program is stopped, then the "interrupted" program status is displayed there or on reset also
"aborted".
The following program states are available in the control system:
● IS "Program status aborted" (DB3300.DBX0003.4)
● IS "Program status interrupted" (DB3300.DBX0003.3)
● IS "Program status stopped" (DB3300.DBX0003.2)
● IS "Program status running" (DB3300.DBX0003.0)
The effect of commands/signals
The program status can be controlled by activating different commands or interface signals. The following table shows the
resulting program state when these signals are set (status before the signal is set -> Program status running).
Commands
Program execution states
Aborted
Interrupted
Stopped
Running
IS "Reset"
X
IS "NC Stop"
X
IS "NC stop at block limit"
X
IS "NC stop axes and spindles"
X
IS "Read-in disable"
X
IS "Feed stop, channel-sp."
X
IS "Feed stop, axis-sp."
X
Feed override = 0%
X
IS "Spindle stop"
X
M2 in the block
X
M0/M1 in the block
X
IS "Single block"
X
Auxiliary functions output to PLC but not
yet acknowledged
X
10.3.7
Channel status
Channel status
The current channel status is signaled at the interface for the channel. The PLC can then trigger certain responses and
interlocks configured by the manufacturer depending on the status at the interface. The channel status is displayed in all
operating modes.
The following channel status are available:
● IS "Channel status reset" (DB3300.DBX0003.7)
● IS "Channel status interrupted" (DB3300.DBX0003.6)
● IS "Channel status active" (DB3300.DBX0003.5)
The effect of commands/signals
The channel status can be modified through the activation of various commands or interface signals. The following table
shows the resulting channel status when these signals are set (assumed status before the signal is set → Channel status
active).
The "Channel status active" signal is obtained when a part program or part program block is being executed or when the
axes are traversed in "JOG" mode.
