Page #171 background imageLoading...
Page #171 background image
Function Manual
01/2017
171
Number
Identifier
Name
36302
ENC_FREQ_LIMIT_LOW
Encoder limit frequency resynchronization
36720
DRIFT_VALUE
Drift basic value
The machine data marked with * is contained in the parameter set for a gear stage.
17.8.2
Setting data
Number
Identifier
Name
General
41200
JOG_SPIND_SET_VELO
JOG velocity for the spindle
Spindle-specific
43230
SPIND_MAX_VELO_LIMS
Programmable spindle speed limit G96
17.8.3
Interface signals
Number
Bit
Name
Axis-specific
DB30x.DBD0000
-
M function for the spindle (DINT), axis-specific
DB30x.DBD0004
-
S function for the spindle (REAL), axis-specific
DB380x.DBB0000
-
Feed override
DB380x.DBX0001
.7
Override active
DB380x.DBX0001
.5
Position measuring system 1
DB380x.DBX0001
.3
Axis/spindle disable
DB380x.DBX0002
.2
Spindle reset/delete distance-to-go
DB380x.DBX0002
.1
Controller enable
DB380x.DBX2000
.3
Gear changed
DB380x.DBX2000
.0 to .2
Actual gear stage A to ...C
DB380x.DBX2001
.4
Resynchronize spindle during positioning 1 (spindle)
DB380x.DBX2001
.6
Invert M3/M4
DB380x.DBX2002
.7
Set direction of rotation counterclockwise
DB380x.DBX2002
.6
Set direction of rotation clockwise
DB380x.DBX2002
.5
Oscillation speed
DB380x.DBX2002 .4 Oscillation via PLC
DB380x.DBB2003
-
Spindle override
DB390x.DBX0000 .7 Position reached with exact stop fine
DB390x.DBX0000
.6
Position reached with exact stop coarse
DB390x.DBX0000
.4
Referenced/synchronized 1
DB390x.DBX0000
.2
Encoder limit frequency exceeded 1
DB390x.DBX0000
.0
Spindle / no axis
DB390x.DBX0001
.7
Current controller active
DB390x.DBX0001
.6
Speed control loop active
DB390x.DBX0001
.5
Position controller active
DB390x.DBX0001
.4
Axis/spindle stationary (n < n
min
)
DB390x.DBX2000
.3
Change gear stage
DB390x.DBX2000
.0 to .2
Actual gear stage A to ...C
DB390x.DBX2001
.7
Actual direction of rotation clockwise
DB390x.DBX2001
.5
Spindle in setpoint range
DB390x.DBX2001
.2
Setpoint speed increased
DB390x.DBX2001
.1
Setpoint speed limited
