Function Manual
01/2017
13
See the following table for the relationship between the two representations.
V Structure
DB Structure
Access
Example
Example
Access
Bit
V38000002.1
DB3800.DBX2.1
Bit
Byte
VB38000002
DB3800.DBB2
Byte
Word
VW38000002
DB3800.DBW2
Word
Double Word
VD38000004
DB3800.DBD4
Double word
3.2
Signals from PLC to NCK
3.2.1
Access authorization
Access authorization
Access to programs, data, and functions is user-oriented and controlled via protection levels. The control system provides a
concept of access levels for enabling data areas. You can view such information from the table below:
Access level
Default password
Target group
Siemens (level 0)
-
Reserved for Siemens
Manufacturer (level 1) SUNRISE Machine manufacturers
End user (levels 3-6)
CUSTOMER
End users
No password (level 7)
-
End users
This provides a multi-level safety concept for controlling access rights.
Reference:
SINUMERIK 808D/SINUMERIK 808D ADVANCED Commissioning Manual, Section: Setting the password
3.2.2
General signals
Delete distance-to-go (DB3200.DBX6.2)
IS "Delete distance-to-go (channel specific)" is only active for path axes.
With the rising edge of the interface signal, the distances-to-go of all axes in the geometry grouping are deleted and thus
brought to a standstill with ramp stop. Then the next program block is started.
Axis/spindle disable (DB380x.DBX1.3)
IS "Axis/spindle disable" can be used for test purposes.
Axis disable (for axis):
If IS "Axis disable" is output - for this axis - no more position partial setpoints are output to the position controller; the axis
travel is therefore disabled. The position control loop remains closed and the remaining following error is reduced to zero. If
an axis is moved with axis disable the actual value position display shows the setpoint position and the actual velocity value
display shows the setpoint velocity even though the machine axis is not actually moving. IS "RESET" (DB3000.DBX0.7) sets
the position actual value display to the real actual value of the machine. Travel commands continue to be output to the PLC
for this axis. If the interface signal is cancelled again the associated axis can again traverse normally. If the interface signal
"Axis disable" is set for a traversing axis, the axis is stopped with a ramp stop.
Spindle disable (for spindle):
If IS "Spindle disable" is set, no more speed setpoints are output to the speed controller in openloop control mode and no
more position partial setpoints are output to the position controller in positioning mode. The movement of the spindle is thus
disabled. The speed actual value display displays the speed setpoint value. The spindle disable is cancelled via "Reset" or
program end (M2) and program restart. If interface signal "Spindle disable" is set while a spindle is turning, the spindle is
stopped according to its acceleration characteristic.
