Siemens SINUMERIK 808D Function Manual

Function Manual
228 01/2017
Note
When a script file "xmldial.xml" is available in the folder above, you can call the start menu in the user
-defined operating
area.
After the initial copying process, res
et the control system through the following operations:
+ → → →
Example of a user dialog on the HMI
The configured softkey menus are displayed when the user-defined operating area is called. This enables the user to
operate the dialog forms which have been configured.
23.10.4
Structure of configuration file
Overview
A configuration file consists of the following elements:
● Description of the "main" start menu with start softkeys
● Definition of dialogs
● Definition of variables
● Description of the blocks
● Definition of softkey bars
23.10.5
Language dependency
Language-dependent texts are used for:
● Softkey labels
● Headers
● Help texts
● Any other texts
