Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
179
Number
Identifier
Name
20201
CHFRND_MODE_MASK
Specifications regarding the chamfer/rounding behavior
Axis-specific machine data
32000
MAX_AX_VELO
Maximum axis velocity
35100
SPIND_VELO_LIMIT
Maximum spindle speed
Channel-specific setting data
42100
DRY_RUN_FEED
Dry run feedrate
42010 THREAD_RAMP_DISP Acceleration behavior of the feedrate axis when thread
cutting
42110
DEFAULT_FEED
Default value for path feed
18.4.2
Interface signals
Number
Bit
Name
Channel-specific
DB3200.DBX0000
.6
Activate dry run feed
DB3200.DBX0004
-
Feed override
DB3200.DBX0005
Rapid traverse override
DB3200.DBX0006
.0
Feed disable
DB3200.DBX0006
.6
Rapid traverse override active
DB3200.DBX0006
.7
Feed rate override active
DB3200.DBX1000
.3
Feed stop, geometry axis 1
DB3200.DBX1004
.3
Feed stop, geometry axis 2
DB3200.DBX1008
.3
Feed stop, geometry axis 3
DB1700.DBX0000
.6
Dry run feed rate selected
DB1700.DBX0001
.3
Feed rate override selected for rapid traverse
DB3300.DBX0001
.2
Revolutional feed rate active
Axis/spindle-specific
DB380x.DBB0000
-
Feed override
DB380x.DBB2003
-
Spindle override
DB380x.DBX0001 .7 Override active (axis or spindle)
DB380x.DBX2001
.0
Feedrate override for spindle valid
DB380x.DBX0004 .3 Feed stop/spindle stop
DB390x.DBX2002
.0
Constant cutting rate active (spindle)
DB390x.DBX2002
.3
Tapping without compensation chuck active (spindle)
19
Tool: tool compensation (W1)
19.1
Tool and tool compensation overview
Characteristics
The control system is capable of calculating the tool compensation data for different tool types (drill, milling cutter, turning
tool, ...).
● Length compensation
● Radius compensation
● Storage of the tool compensation data in the tool offset memory
– Tool identification with T numbers from 0 to 32000
