Siemens SINUMERIK 808D Function Manual

Function Manual
82 01/2017
The following actions are executed when the STOP command is triggered:
● Part program processing is stopped at the next block limit (with NC stop at block limit, M0/M1 or single block), processing
is stopped immediately with the other STOP commands.
● Any auxiliary functions of the current block not yet output, are no longer output.
● The axes are stopped with subsequent stop of the part program processing.
● The block indicator stops at the point of interruption.
10.3.4
RESET command
Function
The RESET command (IS "Reset" (DB3000.DBX000.7)) can be executed in every channel state. This command is aborted
by another command.
A RESET command can be used to interrupt an active part program or part program blocks. After execution of the Reset
command, IS "Channel status reset" (DB3300.DBX0003.7) and the IS "Program status aborted" (DB3300.DBX0003.4) are
set.
The part program cannot be continued at the point of interruption. All axes in the channel are at exact stop.
The following actions are executed when the RESET command is triggered:
● Part program preparation is stopped immediately.
● All axes and if appropriate spindles are braked.
● Any auxiliary functions of the current block not yet output, are no longer output.
● The block indicator is reset to the beginning of the part program.
● All alarms are cleared from the display if they are not POWER ON alarms.
10.3.5
Program control
Selection/activation
The user can control part program processing via the user interface. In "AUTO" operating mode, certain functions can be
selected after you perform the following operations, whereby some functions act on interface signals of the PLC.
→
These signals are merely selection signals from the user interface. They do not activate the selected function.
These signal states must be transferred from the PLC user program to another area of the data block to activate the
selected functions. With program control by the PLC the signals are to be set directly (see the table below).
Function
Selection signal
Activation signal
Checkback signal
SKP skip block
DB1700.DBX0001.0
DB3200.DBX0002.0
DRY dry run feedrate
DB1700.DBX0000.6
DB3200.DBX0000.6
ROV rapid traverse override
DB1700.DBX0001.3
DB3200.DBX0006.6
Preselection:
SBL -single block coarse
SBL -single block fine
Single block
-
-
User-specific
-
-
DB3200.DBX0000.4
M1 programmed stop
DB1700.DBX0000.5
DB3200.DBX0000.5
DB3300.DBX0000.5
PRT program test
DB1700.DBX0000.7
DB3200.DBX0001.7
DB3300.DBX0001.7
