Siemens SINUMERIK 808D Function Manual

Function Manual
70 01/2017
Number
Identifier
Name
32420
JOG_AND_POS_JERK_ENABLE
Enable for axis-spec. jerk limitation
32430
JOG_AND_POS_MAX_JERK
Axis-specific jerk
35130
GEAR_STEP_MAX_VELO_LIMIT[0]...[5]
Maximum velocity for gear stage/spindle
8.6.2
Setting data
Number
Identifier
Name
General information
41010
JOG_VAR_INCR_SIZE
Size of variable increment for INC/handwheel
41110 JOG_SET_VELO JOG velocity for linear axes
41130
JOG_ROT_AX_SET_VELO
JOG speed for rotary axes
41200
JOG_SPIND_SET_VELO
JOG velocity for the spindle
8.6.3
Interface signals
Number
Bit
Name
Signals from HMI to PLC
DB1900.DBX1003
.0 to .2
Axis number for handwheel 1
DB1900.DBX1004
.0 to .2
Axis number for handwheel 2
NCK-specific
DB2600.DBX0001
.0
INC inputs in operating mode range active
Specific to operating mode
DB3000.DBX0000 .2
"JOG" mode
DB3000.DBX0002
.0 to .6
Machine function INC1 up to continuous in operating mode range
DB3100.DBX0000
.2
Active "JOG" mode
Channel-specific
DB3200.DBX1000
DB3200.DBX1004
DB3200.DBX1008
.1, .0
.1, .0
.1, .0
Activate handwheel (2, 1) for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3200.DBX1000
DB3200.DBX1004
DB3200.DBX1008
.4
.4
.4
Traversing-key lock for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3200.DBX1000
DB3200.DBX1004
DB3200.DBX1008
.5
.5
.5
Rapid traverse override for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3200.DBX1000
DB3200.DBX1004
DB3200.DBX1008
.7 or .6
.7 or .6
.7 or .6
Traversing keys plus or minus for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3200.DBX1000
DB3200.DBX1004
DB3200.DBX1008
.0 to .6
.0 to .6
.0 to .6
Machine function INC1 to continuous for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3300.DBX1000
DB3300.DBX1004
DB3300.DBX1008
.1, .0
.1, .0
.1, .0
Handwheel active (2, 1) for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3300.DBX1000
DB3300.DBX1004
DB3300.DBX1008
.7 or .6
.7 or .6
.7 or .6
Traverse command plus or minus for geometry axis 1
for geometry axis 2
for geometry axis 3
DB3300.DBX1001
DB3300.DBX1005
DB3300.DBX1009
.0 to .6
.0 to .6
.0 to .6
Active machine function INC1 to continuous
for geometry axis 1
for geometry axis 2
for geometry axis 3
