; define groove wall offset
Y10
; Y move to position 10
Z-50
; Z move to position -50
Y70
; Y move to position 70
G41 OFFN=-3
; tool radius compensation left of contour
; define groove wall offset
Y10
; Y move to position 10
Z10
; Z move to position 10
R1=R1-0.2
; cutting depth for each step is 0.2 mm
IF R1>15 GOTOB LL
; cutting depth is 5 mm
G40 Y0
; turn off compensation function
TRAFOOF
; turn off TRACYL function
G1 X50 Z50 F1000
; move to safe position
M30
; program finish
12.4
Special features of TRANSMIT and TRACYL
POWER ON/RESET
The system response after POWER ON or RESET (program end) is determined by the settings stored in the following
machine data:
● MD20110 RESET_MODE_MASK (access to this MD only in protection level 1)
● MD20140 TRAFO_RESET_VALUE (active transformation after RESET).
Please note on selection
● Tool radius compensation must be deselected (G40).
● The frame which was active prior to TRANSMIT/TRACYL is deselected by the control. (G500).
● The control deselects an active working area limit for axes affected by the transformation (WALIMOF).
● Continuous path control and rounding are interrupted.
● An instructed intermediate movement block with chamfer or radius is not inserted.
Please note on deselection
● Tool radius compensation must be deselected (G40).
● Continuous path control and rounding are interrupted.
● An instructed intermediate movement block with chamfer or radius is not inserted.
● Following TRANSMIT/TRACYL deselection, zero offsets (Frame) and all settings used for the turning operation are to be
reset.
Operating modes, operating mode changeover
● The program processing with TRANSMIT/TRACYL is performed in "AUTO" mode.
● It is possible to interrupt "AUTO" mode and change over to JOG. When returning to "AUTO" mode, the operator must
ensure a problem-free repositioning of the tool.
● Axes cannot be referenced when a transformation is active.
12.5
Data lists
12.5.1
Machine data
Number
Identifier
Name
Channel-specific
20110 RESET_MODE_MASK Definition of the control basic setting after POWER ON or
RESET/part program end (access only possible at protection level 1)
20140
TRAFO_RESET_VALUE
Initial setting: Transformation active after Reset
22534 TRAFO_CHANGE_M_CODE M code for transformation changeover
