321
23.15.9
Replacing a defective control system hardware (PPU) and/or CF card
If your PPU and/or CF card is defective, both the PPU and the CF card must be replaced at the same time.
After the replacement, the optional functions purchased earlier cannot be activated since the original license key is invalid.
You must first contact the Siemens Hotline to unassign the licenses of the options, and then assign the licenses (Page 326)
and activate the options (Page 327) again on the new control system.
Restoring the machine
Method 1
After the initial power up of the control system with the new PPU and new CF card, an existing commissioning archive
created after you
deactivate
the CNC lock function must be imported.
To create the CNC lock function again, the end user must request a new activation file appropriate for the control system
(.clc) from the machine manufacturer or dealer.
Method 2
After the initial power up of the control system with the new PPU and new CF card, an existing commissioning archive
created after you
activate
the CNC lock function must be imported. After the next power up of the control system, alarm
8062 is displayed and the NC start is disabled. The cause of the alarm is the new serial numbers of the new control system
hardware and new CF card.
To unlock the control system, the end user must request an activation file for deactivating the CNC lock function for the
existing control system from the machine manufacturer or dealer. When creating this activation file, make sure you use the
serial numbers of the new PPU and new CF card as well as the original assigned OEM PIN. For more information about how
to deactivate the CNC lock function with AMM, see Section "Deactivating the CNC lock function (Page 319)".
To create the CNC lock function again, the end user must request a new activation file appropriate for the control system
(.clc) from the machine manufacturer or dealer.
Creating the activation file
The following data is required to create the activation file:
● Serial number of the
new
CF card
● Serial number of the
new
control system (PPU)
● OEM PIN
● Lock date in accordance with the status of the CNC lock function (last lock date or new lock date)
Note
The OEM PIN is newly created here according to the creation rules mentioned earlier.
For more information about how to create an activation file with AMM, see Section "Creating the activation file (Page 316)".
Importing the activation file
The new activation file must be imported into the control system to replace a defective PPU and/or CF card. The machine
manufacturer can import the new activation file directly or send the file to the end user who transfers the file to the control
system. For more information about how to import the activation file, see Section "Importing the activation file (Page 317)".
If no error occurs when importing the activation file, the CNC lock function is active in the new control system.
Note
If
an error occurs when importing the activation file, an error-
specific alarm will be issued. The state of the CNC lock function
remains unchanged.
