Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
39
5.7
Data table
5.7.1
Machine data
Number
Identifier
Name
General
18360
MM_EXT_PROG_BUFFER_SIZE
FIFO buffer size for execution from external source (DRAM)
Channel-specific
20170
COMPRESS_BLOCK_PATH_LIMIT
Maximum traversing length of NC block for compression
20172
COMPRESS_VELO_TOL
Maximum permissible deviation from path feed for compression
20482
COMPRESSOR_MODE
Compressor mode
20490
IGNORE_OVL_FACTOR_FOR_ADIS
G641/G642 independent of the overload factor
28060
MM_IPO_BUFFER_SIZE
Number of NC blocks in IPO buffer (DRAM)
28070
MM_NUM_BLOCKS_IN_PREP
Number of NC blocks for block preparation (DRAM)
28520
MM_MAX_AXISPOLY_PER_BLOCK
Maximum number of axis polynomials per block
28530 MM_PATH_VELO_SEGMENTS Number of storage elements for limiting path velocity in block
28540 MM_ARCLENGTH_SEGMENTS Number of storage elements for arc length function representation
per block
29000
LOOKAH_NUM_CHECKED_BLOCKS
Number of blocks considered by the LookAhead function
Axis/spindle-specific
32310
MAX_ACCEL_OVL_FACTOR
Overload factor for axial velocity jumps
32431
MAX_AX_JERK
Maximum axis-specific jerk for path movement
32432
PATH_TRANS_JERK_LIM
Maximum axis-specific jerk for path movement at block transition
33100
COMPRESS_POS_TOL
Maximum deviation with compensation
36000
STOP_LIMIT_COARSE
Exact stop coarse
36010
STOP_LIMIT_FINE
Exact stop fine
36020
POSITIONING_TIME
Delay time exact stop fine
5.7.2
Setting data
Number
Identifier
Name
General information
42470
CRIT_SPLINE_ANGLE
Core limit angle, compressor
42475
COMPRESS_CONTUR_TOL
Maximum contour deviation in the compressor
5.7.3
Interface signals
Number
Bit
Name
Channel-specific
DB3300.DBX0004
.3
All axes stationary
Axis/spindle-specific
DB390x.DBX0000
.6
Position reached with exact stop coarse
DB390x.DBX0000
.7
Position reached with exact stop fine
