10.7.3
Interface signals
Operating mode signals
Number
Bit
Name
PLC to NCK
DB3000.DBX0000
.0
"AUTO" mode
DB3000.DBX0000
.1
"MDA" mode
DB3000.DBX0000
.2
"JOG" mode
DB3000.DBX0000
.4
Mode change disable
DB3000.DBX0000 .7 RESET
DB3000.DBX0001
.2
Machine function REF
NCK to PLC
DB3100.DBX0000
.0
Active mode "AUTO"
DB3100.DBX0000
.1
Active mode "MDA"
DB3100.DBX0000
.2
Active "JOG" mode
DB3100.DBX0000
.3
808D READY
DB3100.DBX0001
.2
Active machine function REF
Channel signals
Number
Bit
Name
PLC to NCK
DB3200.DBX0000
.4
Activate single block
DB3200.DBX0000
.5
Activate M01
DB3200.DBX0000
.6
Activate dry run feed
DB3200.DBX0001
.0
Activate referencing
DB3200.DBX0001
.7
Activate program test
DB3200.DBX0002 .0 Block skip
DB3200.DBX0006
.0
Feed disable
DB3200.DBX0006 .1 Read-in disable
DB3200.DBX0006
.2
Delete distance-to-go
DB3200.DBX0006
.3
Delete UP number of passes
DB3200.DBX0006
.4
Program level abort
DB3200.DBX0006
.6
Rapid traverse override active
DB3200.DBX0006
.7
Feed rate override active
DB3200.DBX0007
.0
NC Start disable
DB3200.DBX0007
.1
NC Start
DB3200.DBX0007
.2
NC Stop at block limit
DB3200.DBX0007
.3
NC stop
DB3200.DBX0007
.4
NC Stop axes plus spindles
DB3200.DBX0007
.7
Reset
NCK to PLC
DB3300.DBX0000
.3
Action block active
DB3300.DBX0000
.4
Approach block active
DB3300.DBX0000
.5
M00/M01 active
DB3300.DBX0000
.6
Last action block active
DB3300.DBX0001
.0
Referencing active
DB3300.DBX0001
.4
Block search active
