Siemens SINUMERIK 808D Function Manual

Function Manual
76 01/2017
Number
Identifier
Name
22020
AUXFU_ASSIGN_EXTENSION[n]
Auxiliary function extensions
22030
AUXFU_ASSIGN_VALUE[n]
Auxiliary function values
9.7.2
Interface signals
Number
Bit
Name
Channel-specific
DB2500.DBX0000 .0 to .4 M function 1 change to M function 5 change
DB2500.DBX0006
.0
S function 1 change
DB2500.DBX0008 .0 T function 1 change
DB2500.DBX0010
.0
D function 1 change
DB2500.DBX0012
.0 to .2
H function 1 change to H function 3 change
DB2500.DBD2000
T function 1 (DINT)
DB2500.DBD3000
M function 1 (DINT)
DB2500.DBB3004
Extended address of M function 1 (BYTE)
DB2500.DBD3008
M function 2 (DINT)
DB2500.DBB3012
Extended address of M function 2 (BYTE)
DB2500.DBD3016
M function 3 (DINT)
DB2500.DBB3020
Extended address of M function 3 (BYTE)
DB2500.DBD3024
M function 4 (DINT)
DB2500.DBB3028
Extended address of M function 4 (BYTE)
DB2500.DBD3032
M function 5 (DINT)
DB2500.DBB3036
Extended address of M function 5 (BYTE)
DB2500.DBD4000
S function 1 (REAL format)
DB2500.DBB4004
Extended address of S function 1 (BYTE)
DB2500.DBD4008
S function 2 (REAL format)
DB2500.DBB4012 Extended address of S function 2 (BYTE)
DB2500.DBD5000
D function 1 (DINT)
DB2500.DBW6004
Extended address of H function 1 (Word)
DB2500.DBD6000
H function 1 (REAL format)
DB2500.DBW6012
Extended address of H function 2 (Word)
DB2500.DBD6008
H function 2 (REAL format)
DB2500.DBW6020 Extended address of H function 3 (Word)
DB2500.DBD6016
H function 3 (REAL format)
DB2500.DBX1000
.0 - .7
Decoded M signals: M00 - M07
DB2500.DBX1001
.0 - .7
Decoded M signals: M08 - M15
DB2500.DBX1012
.0 - .7
Decoded M signals: M96 - M99
DB370x.DBD0000
-
M function for the spindle (DINT), axis-specific
DB370x.DBD0004
-
S function for the spindle (REAL), axis-specific
