Siemens SINUMERIK 808D Function Manual

Function Manual
170 01/2017
17.8
Data table
17.8.1
Machine data
Number
Identifier
Name
Channel-specific
20090
SPIND_DEF_MASTER_SPIND
Master spindle
Axis-specific
30134
IS_UNIPOLAR_OUTPUT[0]
Setpoint output is unipolar
30300
IS_ROT_AX
Rotary axis
30310
ROT_IS_MODULO
Modulo conversion
30320
DISPLAY_IS_MODULO
Position display
31050 *
DRIVE_AX_RATIO_DENOM[n]
Denominator load gearbox
31060 *
DRIVE_AX_RATIO_NUMERA[n]
Numerator load gearbox
32200 *
POSCTRL_GAIN [n]
Servo gain factor Kv
32810 * EQUIV_SPEEDCTRL_TIME [n] Equivalent time constant speed control circuit for feedforward
control
34040
REFP_VELO_SEARCH_MARKER
Reference point creep speed
34060
REFP_MAX_MARKER_DIST
Monitoring of zero mark distance
34080 REFP_MOVE_DIST Reference point distance/destination point for distancecoded
system
34090
REFP_MOVE_DIST_CORR
Reference point offset/absolute offset, distancecoded
34100
REFP_SET_POS
Reference point value
34200
ENC_REFP_MODE
Referencing mode
35000
SPIND_ASSIGN_TO_MACHAX
Assignment of spindle to machine axis
35010
GEAR_STEP_CHANGE_ENABLE
Gear stage change possible
35040
SPIND_ACTIVE_AFTER_RESET
Spindle active after reset
35100
SPIND_VELO_LIMIT
Maximum spindle speed
35110 *
GEAR_STEP_MAX_VELO[n]
Maximum speed for gear change
35120 *
GEAR_STEP_MIN_VELO[n]
Minimum speed for gear change
35130 *
GEAR_STEP_MAX_VELO_LIMIT[n]
Maximum speed of gear stage
35140 *
GEAR_STEP_MIN_VELO_LIMIT[n]
Minimum speed of gear stage
35150
SPIND_DES_VELO_TOL
Spindle speed tolerance
35200 *
GEAR_STEP_SPEEDCTRL_ACCEL[n]
Acceleration in speed control mode
35210 *
GEAR_STEP_POSCTRL_ACCEL[n]
Acceleration in position control mode
35300
SPIND_POSCTRL_VELO
Position control activation speed
35310 SPIND_POSIT_DELAY_TIME[n] Positioning delay time
35350
SPIND_POSITIONING_DIR
Positioning direction of rotation for a nonsynchronized spindle
35400
SPIND_OSCILL_DES_VELO
Reciprocating speed
35410
SPIND_OSCILL_ACCEL
Oscillation acceleration
35430
SPIND_OSCILL_START_DIR
Starting direction during oscillation
35440
SPIND_OSCILL_TIME_CW
Oscillation time for M3 direction
35450
SPIND_OSCILL_TIME_CCW
Oscillation time for M4 direction
35500
SPIND_ON_SPEED_AT_IPO_START
Feed enable with spindle in setpoint range
35510
SPIND_STOPPED_AT_IPO_START
Feed enable with stationary spindle
36060
STANDSTILL_VELO_TOL
Threshold velocity "Axis/spindle stationary"
36200 *
AX_VELO_LIMIT [n]
Threshold value for velocity monitoring
36300
ENC_FREQ_LIMIT
Encoder limit frequency
