Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
229
23.10.6
XML identifier
23.10.6.1
General structure
Structure and instructions of the script file for dialog configuration
All dialog configurations should be stored in the
DialogGui
tag.
<DialogGui>
…
</DialogGui>
Example:
<?xml version="1.0" encoding="utf-8"?>
<DialogGui>
…
<FORM name ="Hello_World">
<INIT>
<CAPTION>Hello World</CAPTION>
</INIT>
...
</FORM>
</DialogGui>
Instructions
The language offers the following instructions for executing conditional instructions and loop controls:
● For loop
● While loop
● Do while loop
● Conditional processing
● Switch and case instructions
● Operator controls in a dialog form
● Softkey descriptions
● Define variables
For a detailed description of instructions, see Instruction/identifier description (Page 229).
23.10.6.2
Instruction/identifier description
The following
XML tags
are defined for generating dialogs and menus, and for executing program sequences:
Note
Attribute values that are in quotation marks "<...>" should be replaced by the currently used expressions.
Example:
<DATA_LIST action="read/write/append" id="<list name>">
is programmed as follows:
<DATA_LIST action="read/write/append" id="my dat
alist">
Tag identifier
Meaning
BREAK
Conditional cancellation of a loop.
CONTROL
The tag is used to generate control elements.
