Siemens SINUMERIK 808D Function Manual

Function Manual
150 01/2017
15.4
Data table
15.4.1
Machine data
Number
Identifier
Name
Axis-specific
36610
AX_EMERGENCY_STOP_TIME
Length of the braking ramp for error states
36620
SERVO_DISABLE_DELAY_TIME
Shutdown delay controller enable
15.4.2
Interface signals
Number
Bit
Name
General
DB2600.DBX0000 .0 Braking on the contour with EMERGENCY STOP
DB2600.DBX0000
.1
EMERGENCY STOP
DB2600.DBX0000
.2
Acknowledge EMERGENCY STOP
DB2700.DBX0000
.1
EMERGENCY STOP active
Operating mode signal area
DB3000.DBX0000
.7
Reset
16
Reference point approach (R1)
16.1
Fundamentals
Why reference?
The control must be synchronized with the position measurement system of each machine axis so that the control can detect
the exact machine zero when it is switched on. This process is known as referencing.
The spindle process (synchronizing) is largely described in Chapter "Spindle (S1) (Page 156)".
Position measurement systems
The following position measuring systems can be mounted on the motor:
● Incremental rotary measuring system
● Absolute rotary measuring system
The referencing for the mounted position measuring systems can be set with MD34200 ENC_REFP_MODE ("REF.PIOINT"
mode).
Output cam
An output cam for referencing may be required for linear axes, and its signal has the following tasks:
● Selection of the direction of travel when approaching the zero mark (synchronized pulse)
● Selection of the zero mark, where required.
BERO
A BERO (inductive proximity switch) can be deployed as the encoder for the synchronized pulse (instead of the zero mark of
the position encoder) (preferred for rotary axes, spindles). Here connection is made to the control system via pin6 (DI3) of
terminal X21.
Reference:
SINUMERIK 808D/SINUMERIK 808D ADVANCED Commissioning Manual
