This machine data specifies the ASUP priority as of which machine data MD11602 ASUP_START_MASK is to be
applied. MD11602 is applied from the level specified here up to the highest ASUP priority level 1.
Recommended: MD11604 = 2
● MD20116 IGNORE_INHIBIT_ASUP (execute interrupt program in spite of read-in disable)
In spite of set read-in disable, an assigned user ASUP is processed completely for the interrupt channel with the set bit.
Bit 0 is assigned to interrupt channel 1 (PLCASUP1)
Bit 1 is assigned to interrupt channel 2 (PLCASUP2)
The machine data is effective only if MD11602 ASUP_START_MASK Bit2 = 0
● MD20117 IGNORE_SINGLEBLOCK_ASUP (execute interrupt program completely in spite of single block)
In spite of selected SBL processing mode, an assigned user ASUP is processed completely
for the interrupt channel with the set bit.
Bit 0 is assigned to interrupt channel 1 (PLCASUP1)
Bit 1 is assigned to interrupt channel 2 (PLCASUP2)
The machine data is effective only if
MD10702 IGNORE_SINGLE_BLOCK_MASK Bit1 = 0
10.3.10
Responses to operator or program actions
Responses
The following table shows the channel and program states that result after certain operator and program actions.
The left-hand side of the table shows the channel and program states and the mode groups from which the initial situation
can be selected. Various operator/program actions are listed on the right-hand side of the table, the number of the situation
after the action has been carried out is shown in brackets after each action.
Situa-
tion
Channel status
Program status
Active mode
Operator or program action
(Situation after the action)
R
U
A
N
U
Swit
chg
ear
pro-
tec-
tion
A
A
M
J
1
x
x
x
RESET (4)
2
x
x
x
RESET (5)
3
x
x
x
RESET (6)
4 x x x NC Start (13); mode change
(5 or 6)
5 x x x NC Start (14); mode change
(4 or 6)
6 x x x Direction key (15); mode change
(4 or 5)
7
x
x
x
NC Start (14)
8
x
x
x
NC Start (15)
9 x x x NC Start (13); mode change
(10 or 11)
10 x x x NC Start (16); mode change
(9 or 11)
11 x x x Direction key (17); mode change
(9 or 10)
12 x x x NC Start (13); mode change
(10 or 11)
13
x
x
x
NC Stop (12)
14
x
x
x
NC Stop (7); at block end (5)
