Siemens SINUMERIK 808D Function Manual

Function Manual
92 01/2017
Situa-
tion
Channel status
Program status
Active mode
Operator or program action
(Situation after the action)
R
U
A
N
U
Swit
chg
ear
pro-
tec-
tion
A
A
M
J
15
x
x
x
NC Stop (8); at JOG end (6)
16
x
x
x
NC Stop (10); at block end (10)
17
x
x
x
NC Stop (11); at JOG end (11)
Description
Channel status:
R: aborted
U: interrupted
A: running
Program status:
N: aborted
U: interrupted
S: stopped
A: running
Operating modes:
A: AUTO
M: MDA
J: JOG
10.3.11
Example of a timing diagram for a program run
Examples of signals during a program run:
10.4
Program test
10.4.1
General information on the program test
Purpose
Several control functions are available for testing a new part program. These functions are provided to reduce danger at the
machine and time required for the test phase. It is possible to activate several program test functions simultaneously.
