Function Manual
22 01/2017
Variable cuttEdgeParam [r/w]
(EdgeNo - 1) * numCuttEdgeParams + ParameterNo (WORD)
T number (1...32000) (WORD)
Write: Data to NCK variable x (data type of the variables: REAL)
Read: Data from NCK variable x (data type of the variables: REAL)
Variable numCuttEdgeParams
Number of P elements of an edge
Variable numCuttEdgeParams [r]
Read: Data from NCK variable x (data type of the variables: WORD)
Translation of a settable work offset (channel-specific settable frames)
They only exist if MD18601 MM_NUM_GLOBAL_USER_FRAMES > 0.
There are the frame indices:
● 0: ACTFRAME = current resulting work offset
● 1: IFRAME = current settable work offset
● 2: PFRAME = current programmable work offset
● 3: EXTFRAME = current external work offset
● 4: TOTFRAME = current total work offset = total of ACTFRAME and EXTFRAME
● 5: ACTBFRAME = current total base frame
● 6: SETFRAME = current 1st system frame (PRESET, scratching)
● 7: EXTSFRAME = current 2nd system frame (PRESET, scratching)
● 8: PARTFRAME = current 3rd system frame (TCARR and PAROT with orientable tool carrier)
● 9: TOOLFRAME = current 4th system frame (TOROT and TOFRAME)
● 10: MEASFRAME = result frame for workpiece and tool gauging
● 11: WPFRAME = current 5th system frame (workpiece reference points)
● 12: CYCFRAME = current 6th system frame (cycles)
The max. frame index is 12.
The value of numMachAxes is contained in the variable with variable index 4.
Frame index * numMachAxes + axis number
Read: Data from NCK variable x (data type of the variables: REAL)
