Function Manual
01/2017
331
$TC_DP24[Tool number, 1] Tool's dimension:
0: normal
Number of the tool turret
Global user data (integral)
_ZSFR[n] Global user data (float)
Since this data has been used in the Siemens standard
technology cycles, ensure that there is no conflict with the
technology cycles when you are using this data.
Total time for running programs in "AUTO" mode
Run time of a selected program
Cutting time (G01, G02, G03) of a selected program
Time elapsed since the last power-on with default values
Time elapsed since the last normal power-on
$AC_REQUIRED_PARTS Required parts to be counted
Activated by setting MD27880 BIT0 = 1:
• BIT 1 = 0: if "
" = "
", alarm or
interface DB3300.DBX4001.1 = 1
$AC_TOTAL_PARTS Total number of counted parts
Activated by setting MD27880 BIT 4 = 1:
• BIT 5 = 0: M02/M30 increases "
" to "
"
• BIT 5 = 1: the M code defined by MD27882 increases
"
" to "
"
• BIT 6 = 0/1: the counter does not work when "
Program
test" is inactive
$AC_ACTUAL_PARTS Parts actually counted
Activated by setting MD27880 BIT 8 = 1:
• BIT 9 = 0: M02/M30 increases "
" to "
"
• BIT 9 = 1: the M code defined by MD27882 increases
"
" to "
"
• BIT 10 = 0/1: the counter does not work when "
Pro-
gram test" is inactive
