P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
1002 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Declaration
Call example
As far as timing is concerned, the basic program can be executed after other user programs. This is advisable
since the FC5 circuitry will place the PLC in Stop mode.
This example contains the standard declarations for OB 82 and OB 86 and the call of the basic program block.
FUNCTION FC 5: VOID
VAR_INPUT
PlcStop: BOOL:= TRUE;
END_VAR
ORGANIZATION_BLOCK OB 82
VAR_TEMP
OB82_EV_CLASS : BYTE ;
OB82_FLT_ID : BYTE ;
OB82_PRIORITY : BYTE ;
OB82_OB_NUMBR : BYTE ;
OB82_RESERVED_1 : BYTE ;
OB82_IO_FLAG : BYTE ;
OB82_MDL_ADDR : INT ;
OB82_MDL_DEFECT : BOOL ;
OB82_INT_FAULT : BOOL ;
OB82_EXT_FAULT : BOOL ;
OB82_PNT_INFO : BOOL ;
OB82_EXT_VOLTAGE : BOOL ;
OB82_FLD_CONNCTR : BOOL ;
OB82_NO_CONFIG : BOOL ;
OB82_CONFIG_ERR : BOOL ;
OB82_MDL_TYPE : BYTE ;
OB82_SUB_NDL_ERR : BOOL ;
OB82_COMM_FAULT : BOOL ;
OB82_MDL_STOP : BOOL ;
OB82_WTCH_DOG_FLT : BOOL ;
OB82_INT_PS_FLT : BOOL ;
OB82_PRIM_BATT_FLT : BOOL ;
OB82_BCKUP_BATT_FLT : BOOL ;
OB82_RESERVED_2 : BOOL ;
OB82_RACK_FLT : BOOL ;
OB82_PROC_FLT : BOOL ;
OB82_EPROM_FLT : BOOL ;
OB82_RAM_FLT : BOOL ;
OB82_ADU_FLT : BOOL ;
OB82_FUSE_FLT : BOOL ;
OB82_HW_INTR_FLT : BOOL ;
